Create

Create a Docker App

A Docker App is a standard docker container and is created and developed like any normal container for docker and Kuberenetes.

You can build for both x86_64 and arm64 devices.

At a minimum to be compatible with Kelvin, you need two files.

For this example we will get ready for deploying a stock Node Red Server to the edge which can then be accessed on the local LAN network at port 1880 in any modern broswer.

app.yamlDockerfile

The app.yaml is the main configuration file that holds both Kelvin SmartApps™ definition as well as the deployment/runtime configuration.

For our example it would look like this;

app:
docker:
    args: []
    context: .
    dockerfile: Dockerfile
type: docker
info:
    description: Local Node Red Server Demo
    name: local-node-red-server-demo
    title: Local Node Red Server Demo
    version: 1.0.0
spec_version: 4.11.0
system:
ports:
    - name: http
    type: host
    host:
        port: 1880
privileged: false
volumes:
    - name: data
    target: /data
    type: persistent

It is composed by the following sections:

The spec_version section is automatically injected and specifies Kelvin SmartApps™ JSON Schema (latest) version which both defines and validates the app.yaml structure.
```
spec_version: 4.11.0
```
The info section holds Kelvin SmartApps™ basic information required to make itself uploadable to Kelvin's App Registry.
```
info:
    description: Local Node Red Server Demo
    name: local-node-red-server-demo
    title: Local Node Red Server Demo
    version: 1.0.0
```
The name is the Docker App's unique identifier. The title and description will appear in App Registry on the Kelvin UI once the Docker App is uploaded.

Info

The version should be bumped every time Kelvin SmartApps™ gets an update, and before it gets uploaded to the App Registry.
The app:docker can be considered the app.yaml "main" section. It defines the docker configurations and arguments for building the container.
```
app:
    type: docker
    docker:
        args: []
        context: .
        dockerfile: Dockerfile
```
Info

This is the minimum information that you need to give.

The system section is [optional] and can be used to set different system requirements/constraints within the Docker App's running environment. i.e. Resources, Environment Variables, Volumes, Ports, etc:

system:
    ports:
        - name: http
        type: host
        host:
            port: 1880
    privileged: false
    volumes:
        - name: data
        target: /data
        type: persistent

In cases where you want to limit resources a container uses you can add resources which defines the reserved (requests) and limits the resources allocated to the Docker App:

system:
    resources:
        requests:   # Reserved
            cpu: 100m
            memory: 256Mi
        limits:     # Limits
            cpu: 200m
            memory: 512Mi

environment_vars is used to define Environment Variables available within the Docker App container. i.e.:
```
system:
    environment_vars:
        - name: KELVIN_GW_MODE
          value: SOCKETS
```
Info

KELVIN_GW_MODE is an Environment Variable that is [required] by Kelvin's platform. Others can optionally be added.

Mounted volumes are [optional] and their main purpose is to share and persist data generated by Kelvin SmartApps™ or used by it in a specific place. They act like a shared folder between the Docker App and the host. Kelvin supports directory volumes, such as folders or serial ports, persistent, and file/test volumes:

system:
    volumes:
        # Folder Volume
        - name: serial-rs232
          target: /dev/rs232 # Container path
          type: host
          host:
            source: /dev/ttyS0 # Host path

        # Persistent Volume
        - name: extremedb
          target: /extremedb/data
          type: persistent

        # File/Text Volume
        - name: model-parameters
          target: /opt/kelvin/data/parameters.bin
          type: text # Renders data into a file
          text:
            base64: true
            encoding: utf-8
            data: |-
                SGVsbG8gUHJvZHVjdCBHdWlsZCwgZnJvbSB0aGUgRW5naW5lZXJpbmcgR3VpbGQhCg==

ports is [optional] and used to define network port mappings. i.e.:

system:
    ports:
        - name: http
        type: host
        host:
            port: 1880

        - name: opcua
          type: service # Exposed as a service for other containers
          service:
            port: 48010
            exposed_port: 30120

privileged is [optional] and used to grant extended privileges to Kelvin SmartApps™, allowing it to access any devices on the host, such as a Serial device:
```
system:
    privileged: true
```

The Dockerfile is a script used to define the instructions and configuration for building a Docker image. It specifies the base image, installation of software, file copying, and other setup tasks needed to create a reproducible and isolated environment for running Kelvin SmartApps™ in Docker containers.

For example if you wanted to create a basic Node Red Server for deployment to the edge, your Dockerfile can look something like this;

FROM nodered/node-red
